AP 4340
Details:
- Product Line:
- Archive, Archived Amplifiers, Archived Auditor
- Download:
- Infosheet (PDF)
- Download:
- Specsheet (PDF)
4/3/2-Channel A/B Class Amplifier
- Aluminum chassis- High heat dissipation
- RCA inputs- After-Market headunit
- Crossover settings- Low-pass/High-pass, Bass boost adjustment
- Bridgeable
- Stable under 2Ω
Specifications:
| CEA Power (4Ω) | 4 x 70W RMS |
|---|---|
| Max power (2Ω) | 4 x 95W |
| Max power (Bridged 4Ω) | 2 x 190W |
| High-pass Crossover (Ch 1-2) | 60Hz – 1.2kHz |
| High-pass Crossover (Ch 3-4) | 100Hz – 2.2kHz |
| Low-pass Crossover | 50 – 250Hz |
| Full range mode Bandwith | 10Hz- 30kHz |
| Dimensions | 13-25/64″ x 2″ x 9-1/4″ (340x50x235mm) |
